Designed for demanding compaction applications, the SEM512 combines a reliable hydrostatic drive system, dual-amplitude vibration and up to 45% gradeability for productive operation across slopes and uneven terrain.
The SEM512 is a 12-tonne soil compactor developed for road construction, infrastructure, municipal works and demanding site-development projects. Its hydrostatic drum and rear-axle drive deliver dependable traction and straightforward operation. The dual-amplitude vibration system enables operators to adapt compaction performance to different materials and site conditions.
The hydrostatic drive system uses proven variable-displacement piston pumps and motors to provide dependable performance in demanding working conditions.
The dual-amplitude and dual-frequency vibration system helps operators achieve effective compaction across different soil types, layers and applications.
Allows the SEM512 to operate effectively on slopes, hills and uneven terrain while maintaining productive machine performance.
Efficient Engine Performance The Weichai WP4 turbocharged engine with air-to-air aftercooling delivers 97.5 kW of gross power. Its efficient combustion and strong torque characteristics support productive operation while helping control fuel consumption.
The SEM512 uses hydrostatic rear-axle and drum drive to provide smooth machine control, dependable traction and straightforward operation.
The pod-style eccentric vibration system provides two amplitude and frequency settings, enabling the operator to select the appropriate compaction performance for the material and application.
The hydraulic system is designed to reduce energy losses, improve operating efficiency and support longer component life.
The modular cooling package supports dependable machine operation in hot and demanding environments.
The hydrostatic operating system makes the SEM512 straightforward to control, helping operators work confidently and efficiently. One lever controls the throttle, while the second controls forward and reverse travel and braking.
Cat Product Link helps customers monitor equipment information and communicate essential machine data to the appropriate personnel. This supports better equipment management, improved machine visibility and more informed maintenance planning.
The SEM512 is suited to infrastructure, public works and site-development applications where consistent and reliable soil compaction is essential.
Select a specification group to review the machine data most relevant to your application.
| Engine model | WP4G130E22 |
| Emissions standard | China Stage II |
| Gross rated power | 97.5 kW |
| Rated speed | 2,200 rpm |
| Peak torque | 560 Nm |
| Peak torque speed | 1,400–1,600 rpm |
| High-ambient capability at sea level | 49°C |
| Cold-weather capability | −10°C |
| Spectator sound level | 112 dB(A) |
| Operator sound level with cabin | 86 dB(A) |
| Operating mass with standard configuration | 12,000 kg ±3% |
| Weight at drum | 6,900 kg ±3% |
| Weight on rear axle | 5,100 kg |
| Static linear load | 310 N/cm |
| Maximum gradeability without vibration | 45% |
| Articulation angle | 33° ±1° |
| Turning outside radius | 5,990 mm |
| Compaction width | 2,130 mm |
| Ground clearance | 442 mm |
| Full-turn hydraulic cycle time | 6 ±0.5 seconds |
| Low-range travel speed | 0–5.5 km/h |
| High-range travel speed | 0–12 km/h |
| High vibration frequency | 33 Hz |
| Low vibration frequency | 30 Hz |
| High amplitude | 1.80 mm |
| Low amplitude | 0.90 mm |
| High centrifugal force | 245 kN |
| Low centrifugal force | 150 kN |
| Overall length | 5,815 mm |
| Overall width | 2,290 mm |
| Overall height | 3,130 mm |
| Wheelbase | 2,900 mm |
| Tread width | 1,600 mm |
| Drum width | 2,130 mm |
| Drum diameter | 1,600 mm |
| Oscillation angle | 10° ±1° |
| Tyre specification | 23.1–26, 12PR |
| Recommended tyre pressure | 0.35 MPa |
The SEM512 combines a practical standard specification with optional operator-comfort features for long shifts and demanding climates.
Explore the SEM510 for reliable compaction performance in a lighter 10-tonne configuration.
SEM510 is a 10-tonne soil compactor designed for reliable and productive work across road construction, infrastructure and site-development applications. Powered by 97.5 kW gross at 2,200 rpm, it combines a matched powertrain and vibratory system for consistent performance with 2,130 mm.
View SEM 510
SEM518 is an 18-tonne soil compactor designed for reliable and productive work across road construction, infrastructure and site-development applications. Powered by WP6G175E20; 129 kW at 2,000 rpm, it combines a matched powertrain and vibratory system for consistent performance with 2,130 mm wide; 1,600 mm diameter; 40 mm thick.
